Hyosung · Current model
Hyosung 8D: drive-up cash recycling.
Drive-up ATM. Specs, where it fits and what to ask before you buy, repair or replace one.
- BrandHyosung
- TypeDrive-up
- StatusCurrent model
Overview
What it is and where it fits.
The 8D (model 8300D in Hyosung’s 2026 brochure) is the drive-up version of the Series 8 platform. It is installed through the wall of a branch to serve a drive-up lane and is serviced from the rear.
Like the 8T, it comes as a cash dispenser, a dispenser with a cash and check deposit module, or a cash recycler with four 2,950-note recycling cassettes and a 2,000-note deposit cassette. Hyosung lists Windows 11 and a 19-inch sunlight-viewable touchscreen, and says the 8D has an upgrade path to video banking and palm vein identification.
Hyosung’s product page and its 2026 brochure publish different cabinet dimensions and wall-kit sizes for the 8D, so we leave them out here. It is designed for bank and credit union branches, not for retail stores.
Specifications
Hyosung 8D specs.
As published by Hyosung. Configurations vary by unit, so confirm the options on any specific machine.
| Model number | 8300D |
|---|---|
| Screen | 19-inch landscape sunlight-viewable TFT LCD touchscreen |
| Cash capacity | Recycling: four 2,950-note recycling cassettes plus a 2,000-note deposit cassette. Dispense only: 3,000-note cassettes, four high (five with the five-high safe) |
| Deposits | Mixed bundles of up to 50 checks and notes per transaction; 2,000-note and 2,000-check cassettes |
| Operating system | Microsoft Windows 11 |
| Card reader | EMV compliant; anti-skimming and anti-shimming optional; integrated contactless reader |
| PIN pad | PCI-compliant PIN pad; ADA audio guidance via earphone jack |
| Safe | UL 291 Level 1 or CEN 1; seismic and heat alarm; heater in safe |
| Locks and security | Kaba Mas Cencon lock; face and hand camera interface; IP camera optional |
| Servicing | Rear access; status indicators for all modules |
| Communication | TCP/IP |
| Receipt printer | 3.1-inch graphical thermal printer |
| Operating temperature | 32°F to 104°F (0°C to 40°C) |
| Other features | Web camera and microphone optional; palm vein scanner optional; backup battery; 2D barcode reader optional |
Hyosung and its model names are trademarks of their respective owners. BayTM is an independent ATM company.
Who it’s for
Made for bank and credit union branches.
Hyosung designs the Hyosung 8D for financial institutions, not for store floors, so it isn’t a machine most businesses buy.
For a store, bar or other business, a retail ATM is simpler, lighter and easier to install. You can ask us about buying one, or get one through free placement, where BayTM chooses the machine that fits your location at no cost to your business.
Before you choose it
- Hyosung publishes different dimensions and wall-kit sizes for the 8D in different documents, so get confirmed measurements before any wall is cut.
- A drive-up lane needs its own planning for traffic flow, lighting and security, beyond the machine itself.
- It is designed for bank branches. It is not a retail ATM.
Your options
Buy it, or get an ATM placed free.
- I
Buy this ATM
The Hyosung 8D is available from BayTM. Tell us about your space and traffic, and we’ll quote current pricing.
Get an equipment quote - II
Get an ATM placed free
Rather not buy? With free placement, BayTM chooses the machine that fits your location, then installs, loads and services it at no cost to your business.
Request a free placement
Questions
About the Hyosung 8D.
Is the Hyosung 8D a good ATM for a business?
Usually not. Hyosung designs the 8D for bank and credit union branches. For a store, bar or other business, a retail ATM is simpler, lighter and easier to install. With BayTM’s free placement, we choose the machine that fits your location at no cost to your business. Request a location review.
How much does a Hyosung 8D cost?
Prices vary by condition and configuration (cassettes, safe, card reader and software), so we don’t publish a list price. Ask us for a quote and we’ll give you current pricing. For the full cost of owning a machine, see how much an ATM costs for a business.
8D or 7D?
Both are drive-up ATMs that go through a branch wall. The 7D comes from Hyosung’s most affordable bank-grade series; the 8D adds the option of cash recycling and runs Windows 11.
Can a dispense-only 8D be upgraded to recycling?
Hyosung says its Series 8 through-the-wall, drive-up and island models ship either as a cash dispenser with a check-and-cash depository or as a four-plus-one cash recycler, and that the non-recycling versions can be upgraded to recycling.
