Hyosung · Discontinued model
Hyosung 2700T: the through-the-wall 2700.
Through-the-wall ATM, no longer in production. Specs, where it fits and what to ask before you buy, repair or replace one.
- BrandHyosung
- TypeThrough-the-wall
- StatusDiscontinued
Overview
What it is and where it fits.
The NH-2700T was the through-the-wall version of Hyosung’s popular 2700. Nautilus Hyosung invited buyers to “step up to a sleek walk-up with rock solid reliability,” with a weatherized, waterproof build for exterior walls.
It shared the 2700’s 10.1-inch screen and tactile function keys, and took a 2,000-note removable cassette that could be upgraded to three. The wall kit came with a 3-inch throat as standard and a 10-inch option, and a rear supervisor panel was optional.
When Hyosung retired the 2700 series in 2019, it said a Force through-the-wall model would follow. That machine is the Force T (MX2800T).
Specifications
Hyosung 2700T specs.
As published by Hyosung. Configurations vary by unit, so confirm the options on any specific machine.
| Model number | NH-2700T |
|---|---|
| Screen | 10.1-inch color TFT LCD; rear supervisor panel optional |
| Cash capacity | 2,000-note removable cassette, upgradable to three |
| Operating system | Microsoft Windows CE 6.0 |
| Card reader | Dip-type reader; IC card reader and anti-skimming optional |
| PIN pad and keys | PCI-compliant EPP, 8 tactile touch function keys |
| Safe | UL 291 business-hours safe |
| Locks | Dial lock standard; electronic, Cencon or S&G optional |
| Wall kit | 3-inch throat standard; 10-inch optional |
| Communication | TCP/IP, dial-up |
| Dimensions (H × W × D) | 72 × 21.5 × 25.24 in |
| Weight | 308 lbs |
| Operating temperature | 32°F to 104°F (0°C to 40°C) |
| Other features | Weatherized (waterproof), illuminated topper, braille keypad, digital receipt |
Hyosung and its model names are trademarks of their respective owners. BayTM is an independent ATM company.
Where you’ll find it
Where it was a good fit.
- Gas stations
A weatherized walk-up in the store wall served drivers without them coming inside.
- Convenience stores
It kept the ATM off a crowded sales floor while staying visible from outside.
- Shopping centers & strip malls
A storefront install could serve walkway traffic for the whole center.
Before you choose it
- The chip reader was optional, so confirm EMV on any unit you keep.
- Replacing it usually means matching the wall opening. Hyosung publishes different dimensions for the Force T, so plan for a site check.
- Parts come from existing stock since the 2700 line ended in 2019.
Your options
Buy, place free, or fix the one you have.
- I
Buy this ATM
BayTM can supply a Hyosung 2700T or a newer equivalent. Tell us about your space and traffic, and we’ll quote current pricing.
Get an equipment quote - II
Get an ATM placed free
Rather not buy? With free placement, BayTM chooses the machine that fits your location, then installs, loads and services it at no cost to your business.
Request a free placement - III
Repair or replace yours
Already have one? Tell us the model and the problem. We’ll tell you honestly whether a repair makes sense or it’s time for a newer machine.
Request ATM service
Questions
About the Hyosung 2700T.
What replaced the Hyosung 2700T?
The Force T (MX2800T), Hyosung’s current retail through-the-wall ATM.
Can you repair my 2700T?
Tell us the symptom and error code through our repair service. If a repair isn’t worth it, we’ll walk you through replacement.
Can I swap a 2700T for a free ATM?
With free placement, BayTM chooses the machine that fits your site, whether that’s another through-the-wall unit or a freestanding machine inside. Request a review.
